Marine Cladding Materials
Aluminum foil glass fiber cloth (LYLBB) is composed of aluminum foil, base cloth and hot soluble (oil glue) adhesive by high temperature compound. According to the use of different special flame retardant adhesive composite form a dense film, aluminum foil with a smooth surface, high reflectivity, vertical and horizontal tensile strength, airtight, impervious to water, good sealing performance. With high shielding rate, strong material toughness, and cost-effectiveness, it is mainly used for protection and insulation.
| Item | Specification | ||||
|---|---|---|---|---|---|
| Code | LBB120 | LBB140 | LBB160 | LBB200 | LBB200 |
| Thickness (mm) | 0.13 | 0.16 | 0.18 | 0.2 | ≥0.20 |
| Weight (g/m2) | 120 | 140 | 160 | 200 | 220 |
| Warp ±3 | 10 | 11 | 12 | 14 | 14 |
| Weft ±3 | 8 | 9 | 10 | 12 | 14 |
| Fireproof | Non-combustible | ||||
| Tear strength(N) | 700 | 720 | 800 | 900 | 1000 |
| Temperature (ºC) | 500 | 500 | 500 | 500 | 500 |
